FT245R - USB FIFO IC The FT245R is the latest device to be added to FTDI’s range of USB FIFO interface Integrated Circuit Devices. The FT245R is a USB to parallel FIFO interface, with the new FTDIChip-ID™ security dongle feature. In addition, asynchronous and synchronous bit bang interface modes are available.

The FT245R is a USB to parallel FIFO interface, with the new FTDIChip-ID™ security. Windows Vista / Longhorn* Windows XP 64-bit.* Windows.

USB to parallel designs using the FT245R have been further simplified by fully integrating the external EEPROM, clock circuit and USB resistors onto the device. The FT245R adds a new function compared with its predecessors, effectively making it a '2-in-1' chip for some application areas. A unique number (the FTDIChip-ID™) is burnt into the device during manufacture and is readable over USB, thus forming the basis of a security dongle which can be used to protect customer application software from being copied. The FT245R is available in Pb-free (RoHS compliant) compact 28-Lead SSOP and QFN-32 packages. Press releases, articles and web links related to the FT245R can be found.

A frequently asked questions page has been created. Product Information. • • • • • • • • • • • • • Key Hardware Features • Single chip USB to parallel FIFO bidirectional data transfer interface.

• Entire USB protocol handled on the chip - No USB-specific firmware programming required. • Simple interface to MCU / PLD / FPGA logic with simple 4-wire handshake interface.

Manual de bomba bosch vp44 overflow. • Data transfer rate to 1 Megabyte / second - D2XX Direct Drivers. • Data transfer rate to 300 kilobyte / second - VCP Drivers. • FTDI’s royalty-free VCP and D2XX drivers eliminate the requirement for USB driver development in most cases. • New USB FTDIChip-ID™ feature.

• FIFO receive and transmit buffers for high data throughput. • 256 Byte receive buffer and 128 Byte transmit buffer utilising buffer smoothing technology to allow for high data throughput. • Adjustable receive buffer timeout. • Synchronous and asynchronous bit bang mode interface options with RD# and WR# strobes allow the data bus to be used as a general purpose I/O port. • Integrated 1024 bit internal EEPROM for storing USB VID, PID, serial number and product description strings. • Device supplied preprogrammed with unique USB serial number.

• Support for USB suspend / resume through PWREN# pin and Wake Up pin function. • In-built support for event characters. • Support for bus powered, self powered, and high-power bus powered USB configurations.

• Integrated 3.3V level converter for USB I/O. • Integrated level converter on FIFO interface and control pins for interfacing to 5V - 1.8V Logic. • True 5V / 3.3V / 2.8V / 1.8V CMOS drive output and TTL input.
